Eman PTFE Lining is a top manufacturer and supplier of high-quality Teflon Lined Fittings for use in harsh industrial conditions. Based in Tarboul, Egypt, we are experts at the production of FEP, PFA, and PTFE lined components that perform consistently in applications exposed to corrosive chemicals and extreme heat. Our fittings are made to provide long-term strength, durability and chemical stability. They incorporate an internal smooth finish to provide improved flow and sealing characteristics and are available in specialty geometries to meet specific application requirements
Teflon Lined Fittings are industrial-grade pipe fittings lined on the inside with PTFE (Teflon). A chemically inert fluoropolymer that has excellent resistance to aggressive chemicals and heat. The fittings have a smooth, non-stick interior surface, which removes contamination, reduces friction and gives a leak-free seal. Teflon Lined Fittings are used in chemical processing, pharmaceutical, water treatment, and food processing applications. The fittings provide safe and clean handling of fluid while extending the piping system’s life.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : Teflon
Eman PTFE Lining is a leading supplier of Teflon Lined Pipe Fittings in Tarboul, Egypt, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
NB | ID | RF | OD | PCD | No.Of Holes x Dia Of Holes | Lining Thickness Standard | Lining Thickness Full Vacuum | Length Max. |
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Withstands aggressive acids, alkalis, and solvents without degrading.
Performs reliably in elevated temperature environments up to 260°C.
Ensures tight, secure connections for safe and efficient operation.
Offers durability and reduces maintenance costs in harsh industrial settings.
Used in chemical, pharmaceutical, and food industries where corrosion resistance and contamination-free flow are critical for safety and efficiency.
Teflon lined fittings are available in standard sizes from 25mm to 300mm, with custom sizes upon request.
Yes, they can typically handle temperatures up to 260°C depending on the specific process and pressure requirements.
Absolutely, they provide excellent resistance to most strong acids, alkalis, and solvents in demanding chemical environments.
Yes, Teflon lining ensures tight sealing, preventing leakage and minimizing maintenance or safety issues in industrial operations.
We are the leading Manufacturer and Supplier of PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Tarboul, Egypt.
